MODEL SPECIFIC REQUIREMENTS & INSTALLATION
MVP Hydra Vs. MVP:
The MVP Hydra and MVP models dier based on the how many pumps and motors per group head they
have, as well as the funconality that the pump assemblies provide. The MVP Hydra model machine comes
with a pump and motor for each group head, with each pump having a bypass assembly. The MVP has a sin-
gle pump and motor for the enre machine and does not come with a bypass assembly.
In addion, the MVP Hydra has internal plumbing and wiring to accommodate separate and disnct pres-
sures in each brew group. Having individual pumps and motors allows the operator to control brewing pres-
sure at each group head. Each brew group also funcons independently without aecng the pressure at
the other groups.
Because of these dierences the two models have slightly dierent installaon processes and require-
ments. Please read below for details.
Model Specic Color Coding:
Depending on the MVP Series model and number of groups, color-coded zip es will be present on the wa-
ter lines, electrical cords, and pump/motors.
The colors are as follows:
• Group 1: Grey
• Group 2: Purple
• Group 3: Brown
• Water inlet for the steam tank: Pink
• Oponal Line Boost System: Red
Wherever these colors are seen, it is crical for proper machine funcon that they are matched up correctly
(grey to grey, etc.) for both electrical and plumbing systems.
Model Specic Electrical Requirements:
The mulple pump, MVP Hydra machines have a slightly greater amp draw than the single pump, MVP ma-
chines; please note the max amp draws and plan your electrical installaon accordingly. See table on page
10.
For the MVP Hydra package, the pump/motor cords should be matched to the appropriate pump/motor by
the color of zip e. See above for details regarding the dierent colors.
MVP Pump Assembly MVP Hydra Pump
Assembly with Bypass
