How to Replace Hard Disk Backplane for 8 bay/5 bay DiskStation
Page 26 of 39
Date: 2014/4/11
Issued by: Hardware Development Group, Synology
®
Inc.
 Fix the five (5) screws (Marked by the red circles) to secure the replacement
HDD backplane. (Fig. 42 and Fig. 43)
Fig. 42
Fig. 43
HDD Chassis
Replacement
HDD Backplane
PSU Cable
Connect
or
Front Panel
HDD Chassis
Replacement
HDD Backplane
