How to Replace Hard Disk Backplane for 8 bay/5 bay DiskStation
Page 39 of 39
Date: 2014/4/11
Issued by: Hardware Development Group, Synology
®
Inc.
2.2.18 Restore the enclosure cover to its original location. (Fig. 68)
Fig. 68
2.2.19 Fix the six (6) screws on the rear panel (Marked by the red circles) to secure the
enclosure cover. (Fig. 69)
Fig. 69
2.3 The replacing task is completed.
