Systema Eolo 20AE Series - Position of the Ignition and Detection Electrodes; Position of the Nozzle

Gas airtight suspended warm air heaters - EOLO
18
SYSTEMA S.p.A.
Rev. 10EE0112
Fig. 12a Position of nozzles
Fig. 11 Position of electrodes
Fig. 12b Position of nozzles - second flame level
(Eolo 70 AE/AC, Eolo 90 AE/AC)
3.6 Position of the ignition and detection electrodes
3.7 Position of the nozzle
