TA I NSTRUMENTS TGA 2050 2–21
Unpacking the
Balance
When unpacking the balance, be careful not to
damage the balance arm or hang-down loops.
1. Using the 7/64-inch ball driver supplied in
your TGA accessory kit, loosen and remove
the six screws securing the balance chamber
faceplate to the instrument.
2. Take off the faceplate.
3. Loosen and remove the thumbscrew holding
the balance cover on the sample (left) side
of the balance mechanism (Figure 2.12), and
take off the cover. Repeat this step for the
tare (right) side of the balance mechanism.
Figure 2.12
Interior of
Balance Chamber
Before Unpacking
Unpacking the Balance
t CAUTION:
Balance
Cover
Sample
Side
Tare
Side
Tare
Tube
Balance
Cover
Screw
Hang-Down
Loop
