Installing the TGA 2050
2–12 TA I NSTRUMENTS TGA 2050
Connecting
Cables and Lines
To connect the cables and water and gas lines,
you will need access to the TGA instrument’s
rear panel. All directional descriptions are
written on the assumption that you are facing the
back of the instrument.
Connect all cables before connecting the power
cords to outlets. Tighten the thumbscrews on all
computer cables.
Whenever plugging or unplugging power cords,
handle them by the plugs, not by the cords.
Protect power and communications cable
paths. Do not create tripping hazards by
laying them across accessways.
Heat Exchanger Cable
and Water Lines
1. Locate the cooling accessory connector on
the left rear of the instrument cabinet
(Figure 2.6).
2. Connect the heat exchanger cable to the
connector. The heat exchanger cable is the
only cable that fits into this connector.
! WARNING
NOTE:
tt
tt
t CAUTION:
