Installing the TGA 2050
2–30 TA I NSTRUMENTS TGA 2050
Figure 2.17
Aligning the Sample
Pan in the Furnace
4. Press the FURNACE key to lower the
furnace.
5. Press the UNLOAD key to remove the
sample pan from the furnace.
6. Replace the balance chamber faceplate and
its 6 screws.
If you had to load the sample pan manually
in order to align it in the furnace, you should
now adjust the sample platform using the
procedure described on the next page.
Furnace
Housing
Hang-Down
Tube
Sample
Pan
