TA I NSTRUMENTS TGA 20504–12
The cooling gas fitting is located on the left
side of the instrument back and is for furnace
cool-down air.
The rear panel (Figure 4.6) has the signal and
power connections for the instrument; the fuses;
the ready light; the POWER switch; the address
switches; the purge, gas, cooling accessory, and
GPIB connections; and the Reset button.
Figure 4.6
Rear Panel
FUSE
FUSE
