Mode Program Header
and Data Description
Display
VFRQ Frequency
VAMP Amplitude
VOFS Offset
VWID Pulse Width (model 8021)
VCAR Carrier Level (model 8022)
VSTP Sweep Stop Frequency
VSWT Sweep Time
VRPT Internal Trigger Period
VMRK Sweep Marker Frequency
VDCO DC Output Level
Sweep Mode
S0 Sweep Off
S1 Log Sweep - Start to Stop (up)
S2 Log Sweep - Stop to Start (down)
S3 Log Sweep - Start to Stop to Start
S4 Log Sweep - Stop to Start to Stop
S5 Lin Sweep - Start to Stop (up)
S6 Lin Sweep - Stop to Start (down)
S7 Lin Sweep - Start to Stop to Start
S8 Lin Sweep - Stop to Start to Stop
Operating Mode
V0 VCO Mode Off
V1 VCO Mode On
A0 Amplitude Modulation Off
A1 Amplitude Modulation On
P0 Pulse Width Off
P1 Pulse Width On
O0 Offset Off
O1 Offset On
Trigger Mode
G0 Gate Mode Off
G1 Gate Mode On
T0 Trigger Mode Off
T1 Trigger Mode On - External Trigger
T2 Trigger Mode On - Internal Trigger
Output Mode
C0 (model 8021) Pulse Complement Off; Ramp Down Off
C1 (model 8021) Pulse Complement On; Ramp Down On
B0 Output Stand-by Off
B1 Output Stand-by On
Table 4-5. Device-Dependent Command Summary
