Table 8-3. Model 8021 Parts List - Front Panel Board Assembly
REF DESCRIPTION PART #
C1 CAP ELEC 470 16V 1532-04770
C2 CAP CER .1 -20%+80% 50V 1500-01040
CR1 DIODE 1N4151 0300-00400
CR2 DIODE 1N4151 0300-00400
CR3 DIODE 1N4151 0300-00400
DS1 LED HDSP 7501 7 SEG 6020 1200-10200
DS2 LED HDSP 7501 7 SEG 6020 1200-10200
DS3 LED HDSP 7501 7 SEG 6020 1200-10200
DS4 LED HDSP 7501 7 SEG 6020 1200-10200
DS5 3MM LED RED 5082-4480 1000-00300
DS6 3MM LED RED 5082-4480 1000-00300
DS7 LED RED MV 57124-18 G.I 1000-00700
DS8 LED RED MV 57124-18 G.I 1000-00700
DS9 LED RED MV 57124-18 G.I 1000-00700
DS10 LED RED MV 57124-18 G.I 1000-00700
DS11 3MM LED RED 5082-4480 1000-00300
DS12 LED RED MV 57124-18 G.I 1000-00700
DS13 LED RED MV 57124-18 G.I 1000-00700
DS14 LED RED MV 57124-18 G.I 1000-00700
DS15 LED RED MV 57124-18 G.I 1000-00700
DS16 LED RED MV 57124-18 G.I 1000-00700
DS17 LED HDSP 7507 +/- 16020 1200-10100
DS18 LED HDSP 7501 7 SEG 6020 1200-10200
DS19 LED RED MV 57124-18 G.I 1000-00700
DS20 LED RED MV 57124-18 G.I 1000-00700
DS21 LED RED MV 57124-18 G.I 1000-00700
DS22 LED RED MV 57124-18 G.I 1000-00700
REF DESCRIPTION PART #
DS23 LED RED MV 57124-18 G.I 1000-00700
DS24 LED RED MV 57124-18 G.I 1000-00700
DS25 LED RED MV 57124-18 G.I 1000-00700
DS26 LED RED MV 57124-18 G.I 1000-00700
DS27 LED RED MV 57124-18 G.I 1000-00700
DS28 3MM LED RED 5082-4480 1000-00300
Q1 TSTR 2N4403 0400-01800
Q2 TSTR 2N4403 0400-01800
Q3 TSTR 2N4403 0400-01800
Q4 TSTR 2N4403 0400-01800
Q5 TSTR 2N4403 0400-01800
Q6 TSTR 2N4403 0400-01800
Q7 TSTR 2N4403 0400-01800
Q8 TSTR 2N4403 0400-01800
R1 RES COMP 220 0100-02210
R2 RES COMP 220 0100-02210
R3 RES COMP 220 0100-02210
R4 RES COMP 220 0100-02210
R5 RES COMP 33 0100-03300
R6 RES COMP 220 0100-02210
R7 RES COMP 33 0100-03300
R8 RES COMP 220 0100-02210
R9 RES COMP 220 0100-02210
R10 RES COMP 220 0100-02210
S1-S18 SWITCH KEY 2000-61600
U1 IC 74LS138 0510-02700
Table 8-4. Model 8021 Parts List - Pulse Generator Board Assembly
REF DESCRIPTION PART #
C79 CAP TANT 10 35V 1540-0106A
C80 CAP POL 1 1%63V 1520-01050
C81 CAP POLY .1 1% 63V FKE 1520-01040
C82 CAP POLY 4700P 2% 160V 1520-04720
C83 CAP POLY 4700P 2% 160V 1520-04720
C84 SELECTED VALUE (560P MICA TYP)
C85 CAP MICA 820P 10% 300V 1510-08210
C86 SELECTED VALUE (560P MICA TYP)
C87 CAP CER 33P 20% 50V 1500-03300
C88 CAP MICA 56P 10% 500V 1510-05600
C89 CAP VAR 5-18P DV11PS18A 1550-01800
C90 CAP CER 1n 20% 50V 1500-01020
C91 CAP CER .1 -20%+80% 50V 1500-01040
C92 CAP CER .1 -20%+80% 50V 1500-01040
C93 CAP CER .1 -20%+80% 50V 1500-01040
C94 CAP CER .1 -20%+80% 50V 1500-01040
C95 CAP CER .1 -20%+80% 50V 1500-01040
C96 CAP CER 10P 20% 50V 1500-01000
C97 CAP CER .1 -20%+80% 50V 1500-01040
C98 CAP CER .1 -20%+80% 50V 1500-01040
C99 SELECTED VALUE
C100 CAP CER .1 -20%+80% 50V 1500-01040
C101 SELECTED VALUE
C102 CAP CER .1 -20%+80% 50V 1500-01040
REF DESCRIPTION PART #
C103 CAP CER .1 -20%+80% 50V 1500-01040
C104 CAP CER .1 -20%+80% 50V 1500-01040
C105 CAP CER .1 -20%+80% 50V 1500-01040
C106 CAP ELECT 100 16V LOW LEAK 1532-0107P
CR35 DIODE CARRIER 5082-2810 0300-10200
CR36 DIODE ZENER 1N756A 0300-20700
CR37 DIODE 1N4151 0300-00400
CR38 DIODE ZENER 1N756A 0300-20700
CR39 DIODE 1N4151 0300-00400
CR40 DIODE 1N4151 0300-00400
CR41 DIODE REF 1N825A 0300-21100
CR42 DIODE 1N4151 0300-00400
CR43 DIODE 1N4151 0300-00400
K5 RELAY 1FA 5V 0900-01100
Q60 TSTR 2N3904A 0400-01200
Q61 TSTR 2N3904A 0400-01200
Q62 TSTR 2N3904A 0400-01200
Q63 TSTR 2N2369A 0400-00900
Q64 TSTR 2N3904A 0400-01200
Q65 TSTR 2N3904A 0400-01200
Q66 TSTR DN5566 0400-40500
Q67 TSTR 2N5087 0400-01900
Model 8020 Parts List
Page 8-7
