Table 8-4. Model 8021 Parts List - Pulse Generator Board Assembly (continued)
REF DESCRIPTION PART #
Q68 TSTR J109 0400-02500
Q69 TSTR J109 0400-02500
Q70 TSTR 2N3904A 0400-01200
Q71 TSTR 2N3904A 0400-01200
Q72 TSTR 2N3904A 0400-01200
Q73 TSTR 2N4392A 0400-40000
Q74 TSTR 2N4392A 0400-40000
Q75 TSTR 2N3904A 0400-01200
Q76 TSTR 2N3904A 0400-01200
R180 RES COMP 1K 0100-01020
R181 RES COMP 1K 0100-01020
R182 RES COMP 2.7 0100-02R70
R184 RES COMP 10K 0100-01030
R185 RES COMP 1K 0100-01020
R186 RES COMP 1K 0100-01020
R187 RES COMP 1K 0100-01020
R188 RES VAR 200 3386F 0203-02010
R189 RES COMP 33 0100-03300
R190 RES MTF 20K 1% 0104-20020
R191 RES COMP 100 0100-01010
R192 SELECTED VALUE (100 1% TYP)
R193 RES MTF 10K 1% 0104-10020
R194 RES COMP 1K 0100-01020
R195 SELECTED VALUE (100 1% TYP)
R196 RES MTF 2K 1% 0104-20010
R197 RES COMP 100 0100-01010
R198 RES MTF 2.26K 1% 0104-22610
R199 RES MTF 215 1% 0104-21500
R200 RES COMP 10K 0100-01030
R201 RES MTF 1K 1% 0104-10010
R202 RES COMP 22K 0100-02230
R203 RES COMP 22K 0100-02230
R204 RES COMP 22K 0100-02230
R205 RES COMP 22K 0100-02230
REF DESCRIPTION PART #
R206 RES MTF 4.99K 1% 0104-49910
R207 RES COMP 1K 0100-01020
R208 RES MTF 1.1K 1% 0104-11010
R209 RES COMP 22K 0100-02230
R210 RES COMP 22K 0100-02230
R211 RES VAR 1K 3386F 0203-01020
R212 RES MTF 10K 1% 0104-10020
R213 RES VAR 100 3386F 0203-01010
R214 RES COMP 10K 0100-01030
R215 RES COMP 3.3K 0100-03320
R216 RES MTF 10K 1% 0104-10020
R217 RES COMP 10K 0100-01030
R218 SELECTED VALUE
R219 RES MTF 10K 1% 0104-10020
R220 RES COMP 22K 0100-02230
R221 RES COMP 3.3K 0100-03320
R222 RES COMP 3.3K 0100-03320
R223 RES COMP 3.3K 0100-03320
R224 RES MTF 10K 1% 0104-10020
R225 RES COMP 22K 0100-02230
R226 RES COMP 1K 0100-01020
R227 RES COMP 1K 0100-01020
U30 IC 74HC4094 0520-07400
U31 IC 74F64 0500-12780
U32 IC 74AC74 0505-00800
U33 IC LM741E 0500-56300
U34 IC AD9686BQ 0500-60700
U35 IC LM741C 0500-56310
U36 IC 10 BIT D/A AD7533JN 0560-00700
U37 IC SHIFT REGISTOR CD4094B 0540-01100
U38 IC SHIFT REGISTOR CD4094B 0540-01100
U39 IC DUAL COMP LM318N 0500-53200
U40 IC DUAL COMP LM318N 0500-53200
U41 IC DUAL OP AMP LM1458N 0500-56500
Table 8-5. Model 8022 Parts List - AM Generator Board Assembly
REF DESCRIPTION PART #
C65 CAP CER .1 -20%+80% 50V 1500-01040
C66 CAP CER .1 -20%+80% 50V 1500-01040
C67 CAP CER .1 -20%+80% 50V 1500-01040
C68 CAP TANT 10 35V 1540-0106A
C69 SELECTED VALUE
C70 CAP CER .1 -20%+80% 50V 1500-01040
C71 CAP CER .1 -20%+80% 50V 1500-01040
C72 CAP CER 10n 20% 50V 1500-01030
C73 CAP CER .1 -20%+80% 50V 1500-01040
CR25 DIODE REF 1N825A 0300-21100
CR26 DIODE 1N4151 0300-00400
CR27 DIODE 1N4151 0300-00400
CR28 DIODE ZENER 1N755 0300-20310
CR29 DIODE 1N4151 0300-00400
K4 RELAY RZ-1 0900-00700
L1 FERRITE BEAD 24 57-1355 4200-00000
L2 FERRITE BEAD 24 57-1355 4200-00000
Q47 TSTR 2N5771 0400-00750
REF DESCRIPTION PART #
Q48 TSTR 2N5771 0400-00750
Q49 TSTR 2N5771 0400-00750
Q50 TSTR 2N5771 0400-00750
Q51 TSTR 2N3646 0400-00200
Q52 TSTR 2N3646 0400-00200
Q53 TSTR 2N3904A 0400-01200
Q54 TSTR 2N3906A 0400-01340
R130 RES MTF 4.99K 1% 0104-49910
R131 RES MTF 3.01K 1% 0104-30110
R132 RES COMP 1.2K 0100-01220
R133 RES MTF 4.99K 1% 0104-49910
R134 RES COMP 10K 0100-01030
R135 RES VAR 2K 3386F 0203-02020
R136 RES MTF 1.78K 1% 0104-17810
R137 RES MTF 5.62K 1% 0104-56210
R139 RES COMP 47K 0100-04730
R140 RES MTF 10K 1% 0104-10020
R141 RES MTF 4.99K 1% 0104-49910
Parts List Model 8020
Page 8-8
