Taie FY900 - LEVEL_1 Parameter

29 FY operation manual
10.5 LEVEL_1 Parameter
Parameter
Symbol
Content
Range
Default
Hide/
Display
MAX
MIN
PV
---
Process value
USPL
LSPL
---
---
SV
---
Set value
USPL
LSPL
---
---
OUTL
High limit setting of manipulated value
when PID gain > OUTL use OUTL as
manipulated value
100.0
0.0
100.0
SET1.1
AT
Auto-tuning execute selection
0 : NO (PID control)
1 : YES (execute auto-tuning)
2 : PR.TU (Startup tunning, execute once)
3 : PRTU (Startup tunning, execute always
when reboot)
PRTU
NO
NO
SET1.2
*
AL1
Alarm1 set value
(Please refer to Chapter 12)
9999
-1999
1.0
SET1.3
SOAK
Alarm1 soak time
Time format : hr.min
99.59
0.00
0.10
ALD1=10
or
ALD1=19
HBAC
HBA current setting value
Upper : heater current display
Down : current setting value
unit : ampere(A)
100.0
0.0
1.0
INP2=4
&
ALD1=9
*
AL2
Alarm2 set value
(Please refer to Chapter 12)
9999
-1999
1.0
SET1.4
HBAC
HBA current setting value
Upper : heater current display
Down : current setting value
unit : ampere(A)
100.0
0.0
1.0
INP2=4
&
ALD2=9
SOAK
Alarm2 soak time
Time format : hr.min
99.59
0.00
0.10
ALD2=10
or
ALD2=19
*
AL3
Alarm3 set value
(Please refer to Chapter 12)
9999
-1999
1.0
SET2.1
SOAK
Alarm3 soak time
Time format : hr.min
99.59
0.00
0.10
ALD3=10
RAMP
The rate of change during SV ramp
operation
format : °C / minute
(Please refer to Chapter 11.7)
99.99
-19.99
10.00
ALD3=9
&
SET2.1
RATE
Slave SV rate
RATE SV = SV x (RATE/9999)
(Please refer to Chapter 11.9)
9999
0
9999
SET2.1
&
SET0.2
* Automatically display corresponding parameters according to different setting conditions
EX1: When alarm1 is used as HBA function(ALD1= 09), original AL1 will become HBAC display
EX2: When alarm2 is used as SOAK_B function(ALD2= 19), original AL2 will become SOAK display
EX3: When alarm3 is used as RAMP function(ALD3= 09), original AL3 will become RAMP display
