Tait TP9400 Series P25 User Manual

Getting started 39
Name Function
PTT key Press and hold to transmit and release to
listen
Power/volume
control
Rotate to turn the radio on and change
the speaker volume
Channel
selector
Select and change channels
3-way selector
(optional)
Select frequently used features
Left and right
selection keys
Action determined by the text above the
selection key
Scroll keys Scroll up and down through a list of menu
options, scroll left and right in messages,
or select the Quick Access menu
Function keys Programmed for frequently used options
Alphanumeric
keys
Used to enter letters and numbers

Tait TP9400 Series P25 Specifications

General

P25 Phase	Phase 1 and Phase 2
Frequency Bands	VHF: 136-174 MHz, UHF: 380-520 MHz, 700/800 MHz: 764-870 MHz
Operating Temperature	-30°C to +60°C (-22°F to +140°F)
Operating Voltage	7.4V DC (Nominal)
MIL-STD	MIL-STD-810 C/D/E/F/G
Battery Life	Up to 12 hours (depending on usage)
