Tait TP9400 Series P25 User Manual

Getting started 45
Use the following table to record the function keys
programmed for your radio:
For more information about the function keys that can
be programmed on your radio, contact your radio
provider.
Navigating the radio’s menus
Your radio has a number of menus, each containing
lists or submenus. The menus available depend on
the way your radio is programmed.
Using the Main menu
To access the Main menu, press the right selection
key whenever Menu appears above it.
Short key press Long key press
F1
F2
F3
F4
F5
1
1. On speaker microphone (if fitted)
F6
1
Lock Menu
Channel 12
Zone 11

Tait TP9400 Series P25 Specifications

General

P25 Phase	Phase 1 and Phase 2
Frequency Bands	VHF: 136-174 MHz, UHF: 380-520 MHz, 700/800 MHz: 764-870 MHz
Operating Temperature	-30°C to +60°C (-22°F to +140°F)
Operating Voltage	7.4V DC (Nominal)
MIL-STD	MIL-STD-810 C/D/E/F/G
Battery Life	Up to 12 hours (depending on usage)
