Tait TP9400 Series P25 User Manual

Getting started 47
In this example, the Channels menu is the Quick
Access menu. Use the scroll keys to go directly to
the Channels menu.
The Channels menu, with a list of your available
channels, is now displayed.
Using the left selection key Quick
Access menu
The text above the left selection key corresponds to
the Quick Access menu, for example, Zones.
To use this Quick Access menu:
■ Press the left selection key and the associated
menu appears.
Menu
Channel 12
Zone 11
Channels
Channel 1
Channel 2
Back Select
Zones Menu
Channel 12
Zone 11

Tait TP9400 Series P25 Specifications

General

P25 Phase	Phase 1 and Phase 2
Frequency Bands	VHF: 136-174 MHz, UHF: 380-520 MHz, 700/800 MHz: 764-870 MHz
Operating Temperature	-30°C to +60°C (-22°F to +140°F)
Operating Voltage	7.4V DC (Nominal)
MIL-STD	MIL-STD-810 C/D/E/F/G
Battery Life	Up to 12 hours (depending on usage)
