5-30
MAINTENANCE
EVERY 100 HOURS
CLEANING THE WATER SEPARATOR
WARNING
• Do not smoke or permit open flames
while handling fuel or working on the
fuel system.
• Stop the engine in a well-ventilated
place and allow it to cool down before
performing maintenance.
• Clean up spilled fuel immediately.
(S): Close
1. Open the engine hood.
2. Close the valve (2).
3. Loosen the ring (3), then remove the case
(4), element (5) and indicator ring (6) and
clean them.
4. Inspect the O-ring and the element (5). If
there are any scratches or other
irregularities, replace them.
5. Assemble the indicator ring (6), case (4)
and element (5) and tighten the ring (3).
6. Open the valve (2).
7. Loosen the vent plug (8) and bleed the air.
8. Tighten the vent plug (8).
Refer to “Bleeding air from the fuel
system” on page 6-8.
EVERY 100 HOURS
