3-7
OPERA
TION
LEVER P
A
TTERN (JCB P
A
TTERN)
WA
R
N
I
N
G
• Before starting operation, car
efully check which lever patter
n you are going to use.
• It is described using the ISO pattern in this manual.
Left crawler forward
Right crawler forward
Left crawler reverse
Right crawler reverse
Boom lower
Arm out
Boom raise
Arm in
Upperstructure slew left
Bucket load
Upperstructure slew right
Bucket dump
Boom offset left
Dozer blade lower
Boom offset right
Dozer blade raise
OPERA
TING THE MACHINE
84
