2-16
CONTROLS
SWITCHES
AUXILIARY HYDRAULIC BUTTONS
Press those buttons to control the flow of the
oil in the auxiliary hydraulic lines.
• Proportional control of the auxiliary
hydraulic circuit is not possible.
(A) ..................Hydraulic oil flows to left
auxiliary line (a).
(B) .................Hydraulic oil flows to right
auxiliary line (b).
Refer to “Auxiliary hydraulic lines” on page 2-
30.
TRAVEL SPEED SWITCH
WARNING
When a load greater than a set value is
applied while traveling in 2nd (high)
speed, the speed will automatically slow
down to 1st (low) speed. When the load
becomes lighter, the speed will increase
and return to 2nd (high) speed.
Remember that the travel speed changes
depending on the load condition.
Press this switch to set the travel speed to
2nd (high) speed. Press it again to return to
1st (low) speed.
