8-4
OPTIONS
ATTACHMENT COMBINATION TABLE
The table below shows which bucket should be installed when the machine is using a
standard arm. Select a proper bucket by following the table.
WARNING
• Consult with Takeuchi before installing an optional attachment.
• Do not use any attachments not approved by Takeuchi. Doing so may cause safety
problems. Or, it may adversely affect the machine’s operation or service life.
• We will not be held responsible for any injuries, accidents or damage to its products
caused by the use by a non-approved attachment.
• Failure to properly set the Attachment Interference Prevention Switch can result in
equipment damage, serious injury or death.
√ :Can be used.
∆ :Can be used only for light operations (digging and loading of dry and loose soil or mud)
— :Cannot be used.
Bucket
Rated capacity
m
3
(cu. yd.)
Bucket cutting width
mm (inch)
Standard arm
1085 mm (43 in.)
460W (Standard) 0.068 (0.089) 460 (18.1) √
500W 0.077 (0.101) 500 (19.7) √
Hydraulic Breaker (TKB-101)
√
