Takeuchi TB128FR User Manual

7-9
SPECIFICATIONS
<Canopy>
Unit: mm (inch)
Item
Standard arm
Rubber crawlers
A Maximum reach 4785 (188.4)
B
Maximum reach at ground reference
plane
4655 (183.3)
C Maximum digging depth 2575 (101.4)
D Maximum vertical digging depth 2150 (84.6)
E
Reach at maximum vertical digging
depth
2775 (109.3)
F Maximum height of cutting edge 4700 (185)
G Maximum dumping height 3380 (133.1)
H Minimum dumping height 1440 (56.7)
J Dozer blade maximum lifting 320 (12.6)
K Dozer blade maximum lowering 290 (11.4)
<Cab>
Unit: mm (inch)
Item
Standard arm
Rubber crawlers
A Maximum reach 4785 (188.4)
B
Maximum reach at ground reference
plane
4655 (183.3)
C Maximum digging depth 2575 (101.4)
D Maximum vertical digging depth 2150 (84.6)
E
Reach at maximum vertical digging
depth
2775 (109.3)
F Maximum height of cutting edge 4700 (185)
G Maximum dumping height 3380 (133.1)
H Minimum dumping height 1440 (56.7)
J Dozer blade maximum lifting 320 (12.6)
K Dozer blade maximum lowering 290 (11.4)
OPERATING RANGES

Takeuchi TB128FR Specifications

General

Brand	Takeuchi
Model	TB128FR
Category	Compact Excavator
Language	English
