7-5
SPECIFICATIONS
Unit: mm (inch)
Item
Standard bucket
Rubber tracks
A Overall length 3430 (135.1)
B Overall length (without bucket) 2740 (107.8)
C T
rack base 1390 (54.7)
D Overall height 2130 (83.9)/2235 (88.0)*
E Gr
ound clearance of undercarriage 310 (12.1)
F Overall width (without bucket) 1580 (62.2)
G T
rack shoe width 320 (12.6)
H Body width 1430 (56.3)
J Canopy/Cab width 980 (38.6)/985 (38.7) *
K Bucket width 1675 (66.0)
L Bucket height 510 (20.0)
M Departur
e angle 30°
*: With a cab
MACHINE DIMENSIONS
