SWITCHES
IGNITION SWITCH
SWITCHES
IMPORTANT: Do not repeatedly switch
the key from OFF to ON and ON to OFF
over a short period. Doing so will cause
engine breakdown.
PREHEAT Position for pr
eheating the engine.
OFF ......... Position for stopping the engine
and inserting or r
emoving the key.
ON .......... Position in which the engine is
running. At this position, all the
electrical equipment is functional.
ST
ART ..... Position for starting the engine.
When the key is released, the
switch automatically returns to the
ON position.
ENGINE SHUTDOWN SWITCH
This switch is used to shutdown the engine if
it fails to stop, due to machine failure or
breakage, when the ignition key is turned to
the OFF position.
1.
Push the lever (1) forward (STOP).
2. After use, return the lever (1) to the
rearward position.
HORN BUTTON
Press the button situated on the right
operating lever to blow the horn.
