WHEN REQUIRED
REPLACING THE BUCKET OR
ATTACHMENT
WARNING
• Use only the attachments
recommended by us. Using the
attachments not approved by us may
cause safety problems. Also, it may
adversely affect the machine’s operation
or service life.
•
Before performing maintenance or
repairs under the machine, lower all
moveable working equipment to the
ground or in the lowermost position.
For the installation and removal of the
standard bucket provided by us, follow the
procedure below.
For the other attachments, consult Takeuchi
or one of our service agents.
Installation
Befor
e installing a bucket, clean the
connecting sections of the bucket (1) and the
quick-hitch (3) and their surrounding area.
WHEN REQUIRED
1. Make sure the quick-hitch (3) lock levers
(2) are in the unlock position.
2. Sit in the operator’s seat, lower the safety
bar, and then start the engine.
3. Tilt the quick-hitch (3) forward.
4. Slowly move the machine forward and
raise the lift arms. Engage the wedge-
shaped top edge of the quick-hitch (3)
onto the bucket (1) upper part (quick-hitch
mount).
5. Tilt the quick-hitch (3) backward while
lifting the bucket (1) off the ground. The
quick-hitch (3) will slide into position.
6. Keep the bucket (1) at the height of 20 to
50 mm (0.8 to 2 in.) above the ground.
7. Stop the engine and raise the safety bar.
To Next Page
