Unit: mm (inch)
Item
Standard bucket
Rubber tracks
A Maximum raised height of bucket 3905 (153.8)
B Bucket hinge pin height 3030 (119.3)
C Dumping clearance (at 45-degr
ee forward tipping) 2370 (93.4)
D Dumping r
each (at 45-degree forward tipping) 730 (28.8)
E Minimum tur
ning radius (bucket outside) 2080 (82.0)
F Minimum tur
ning radius (front side, without bucket) 1375 (54.1)
G Minimum tur
ning radius (rear side) 1585 (62.4)
H Bucket r
oll back angle (on ground) 30°
OPERATING RANGES
