Connection for recording from other equipment
Connect a VCR or similar recording equipment to the OUT jacks.
1. Connect to Video IN by a video cable.(configuration A+D)
2. Connect to S-video IN by a s-video cable.(configuration B+D)
3. Connect with component video cable.(configuration C+D)
