OPERATING PROCEDURES
6-3
Model 336, 338, 339
Operating Procedures
6
9. Insert the prime plugs into the holes in the top of the
freezer door, and push down.
Figure 6-7
10. Install the freezer door. Insert the baffle rods through
the opening in the beaters and seat the door flush
with the freezing cylinder. With the door seated on
the freezer studs, install the handscrews. Tighten
equally in a crisscross pattern to make sure the door
is snug.
Note: The short handscrews go on the bottom
and the long handscrews go on top.
Figure 6-8
11. Install the three draw valves. Slide the two O-rings
into the grooves on the draw valves, and lubricate.
Figure 6-9
12. Lubricate the inside of the freezer door spouts, top
and bottom, and insert the draw valves from the
bottom until the slot in the draw valves comes into
view.
Figure 6-10
