Taylor C712 Service Manual

4-4
PARTS
Models C712/C713
Parts
4
Model C712 Exploded View Parts Identification
Item Description Part No.
1 Shell A.-Insulated X63324-SER
1a Bearing-Rear Shell 031324
1b Washer-Bearing Lock 012864
1c Nut-Bearing 028991
1d Guide-Drip Seal 028992
2 Coupling-Drive 3/4 Hex 012721
3 Gear A.*Reducer 4.21:1 021286-SER
4 Washer-5/16 SAE Flat 017660-SP
5 Screw-5/16-18X3-1/4 Hex 022678
6 Motor-Reducer-32 RPM 036955-34S
7 Screw-1/4-20X-3/4 Socket 020128-2
8 Pulley-2AK74-5/8 027822
9 Belt-AX32 032769
10 Motor-1.5 HP 021522-27
11 Pulley-2AK22 016403
12 Screw-5/16-18X5/8 SERR. 017326
13 Nut-Flange-5/16-18 Lock 011860
14 Washer-5/16 USS Flat 000651
15 Cap-Rubber Mount 011844
16 Grommet-7/16 X 5/16 016212
17 Spring-Comp.970X.115X2 025707
18 Bolt-Carriage-5/16-18X3 056331
19 Nut-5/16-18 Flange Nut 017327
20 Screw-1/4-20X5/8 SERR 017522
21 Nut-1/4-20 Flange Lock 017523
22 Bushing-Rubber Mount 012258
23 Clamp-Mounting 012257
24 Hinge A.-Motor X25736
25 Caster-4" SWV 3/4-10 STM 044106
26 Caster-4" SWV w/Brake 046437
27 Dryer-Filter-HP62-3/8 048901
28 Valve-Solenoid 7/64ORF 043449-27
29 Screw-10X3/8 Slotted 015582
Item Description Part No.
30 Shroud-Front & Rear 059884
31 Guide A.-Drip Pan-Left X59910
32 Control A. (See Pg 4-13) X67560-27
33 Cover-Control Box 067984
34 Condenser-AC Left 055813-1
Condenser-AC Right 055813-2
35 Guide A.-Filter-Right X59930
36 Panel A.-Front X63879
37 Blower A.-Std Output 
(See Pg 4-27)
X53725-27
38 Shroud-Top 059838
39 Plate-Adaptor-Blower 059926-SP
40 Guide A.-Filter-Left X59931
41 Valve-Exp-Auto-1/4S X1/4 046365
42 Switch-Pressure 440 PSI 048230
43 Compressor 048259-27E
44 Screw-5/16-18X1-3/4 019691
45 Grommet-Compressor 037428
46 Valve-Access-1/4MFL 053565
47 Valve-EPR 1/4S 022665
48 Valve-Access-1/4FL X 1/4 044404
49 Valve-Access-1/4 MFLX1/4 047016
50 Compressor TL3G-R134A 047701-27
51 Kit-MT-Compressor 047704
52 Condenser A.-Danfoss X68077-27G See
Pg 4-28
53 Dryer-Cap. Tube .026ID 047699
54 Panel A.-Front Lower X59854-SER
55 Box A.-Cap&Relay X6540227SP
See Pg 4-17
56 Switch-Toggle-3PDT 068221
57 Plate-DEC 062121
See Pg 4-22
58 Panel A.-Front *Upper X59836
