Taylor C712 Service Manual

PARTS
4-9
Models C712/C713
Parts
4
Model C713 Exploded View Parts Identification
Item Description Part No.
1 Shell A.-Insulated X63337-SER
1a Bearing-Rear Shell 031324
1b Washer-Bearing Lock 012864
1c Nut-Bearing 028991
1d Guide-Drip Seal 028992
2 Coupling-Drive 3/4 Hex 012721
3 Gear A.*Reducer 4.21:1 021286-SER
4 Washer-5/16 SAE Flat Zinc 017660-SP
5 Screw-5/16-18X3-1/4 Hex HD 022678
6 Pulley-2AK64-5/8 Bore 039695
7 Belt-AX30 052191
8 Pin-Retaining-Hopper CVR 043934
9 Stud-Nose Cone 055987
10 Motor-1.5 HP 021522-27
11 Pulley-2AK22 016403
12 Screw-5/16-18X7/8 SERR. 017973
13 Nut-Flange-5/16-18 Lock 011860
14 Washer-5/16 USS Flat CR3 000651
15 Cap-Rubber Mount 011844
16 Grommet-7/16 X 5/16 016212
17 Spring-Comp.970X.115X2.00 025707
18 Bolt-Carriage-5/16-18X3 056331
19 Nut-5/16-18 Whiz Flange 017327
20 Screw-1/4-20X5/8 Serrated 017522
21 Nut-1/4-20 Flange Lock 017523
22 Bushing-Rubber Mount 012258
23 Clamp-Mounting 012257
24 Hinge A.-Motor X25736
25 Caster-4" SWV 3/4-10 Stem 044106
26 Caster-4" SWV 3/4-10 Stem w/
Brake
046437
27 Dryer-Filter-HP62-3/8 048901
28 Valve-Solenoid 7/64ORF 043449-27
29 Screw-10X3/8 Slotted Hex 015582
Item Description Part No.
30 Shroud-Front & Rear 059884
31 Guide A.-Drip Pan-Left X59910
32 Control A. (See Pg 4-15) X67561-27
33 Cover-Control Box 067984-SP1
34 Condenser-AC (Left) 055813-1
Condenser-AC (Right) 055813-2
35 Guide A.-Filter-Right X59930
36 Panel A.-Front X63879
37 Blower A.-Std Output X53725-27
37a Motor-Fan 208-230V 50/60 053481-27
37b Capacitor-Run 7.5UF/370V 034749
38 Shroud-Top 059838
39 Guide A.-Drip Pan-Right X59911
40 Plate-Adaptor-Blower 059926-SP
41 Guide A.-Filter-Left X59931
42 Valve-Access-1/4MFL X 3/8 053565
43 Switch-Pressure 440 PSI 048230
44 Valve-Access-1/4FL X 1/4 044404
45 Compressor L64A113BBCA 048259-27E
46 Screw-5/16-18X1-3/4 019691
47 Grommet-Compressor MT 037428
48 Valve-EPR 1/4S 022665
49 Compressor TL3G-R134A 047701-27
50 Valve-Access-1/4 MFLX1/4 047016
51 Kit-Mounting-Compressr 047704
52 Condenser A.-Danfoss X68077-27G
See Pg 4-28
53 Dryer-Cap. Tube .026ID 047699
54 Panel A.-Front Lower X59854-SER
55 Box A.-Cap&Relay *Bristol X6540227SP
See Pg 4-17
56 Switch-Toggle-3PDT 068221
57 Panel A.-Front *Upper X59836
58 Plate-DEC 062122
See Pg 4-23
