4-16
PARTS
Models C712/C713
Parts
4
Control Assembly X67561-27 (C713) Parts Identification
*Not Shown, Not Included in X67561-27
Item Description Part No.
1 Control-INTERF-HT-SS 063967-SER
1a PCB A.-ROHS-Person-HT-SS 063922-SER
*1b Cntrl-ROHS-INTF-Hotgas 063926-SER
2 Standoff-Nylon-Snap-1/2L 053413
3 Cable-Ribbon-50C-25"L 040040-025
4 Cable-Ribbon-50C-10"L 040040-058
5 PCB A.-Control *UVC4 X69355-SER
5a Control-UVC4 (Base Board) X68114-SER
6 Cable-Ribbon-20C-14"L 040040-040
7 Cable-Ribbon-20C-16"L 040040-049
8 Screw-8X1/4 SLTD Hex 009894
9 Bushing-Snap 15/16 ID 023396
10 Trans.-120/208/240V 051660
11 Block-Terminal 1P 073423
Item Description Part No.
12 Bushing-Snap 1-5/8ID X 2 OD 043637
13 Harness-Wire-Cntrl Box 068007
14 Screw-6X5/16 SLTD Round 013646
15 Relay-DPDT 100UA -7A 1/8HP 052111-03
16 Starter-1 Phase 6.3 to 10A 066794-27K
16a Overload-Thermal-1P 067461-1K
17 Screw-10-32X5/8 UN SL HWH 039382
18 Relay-3 Pole-20A-208/240 066795-33
19 Filter-Corcom 6EH1 040140-001
20 Bushing-Snap 11/16 ID X 7/8 010548
21 Trans.-Cont.-32VA 054834
22 Cable-Ribbon-20C-17"L 040040-013
* Holder-Fuse-Inline-HFA 064538
* Fuse-BUSS-ABC-15-R ROHS 076414
