Introduction
McDonald's Intelligap Grills
150520
Model C835 Specifications
See the data label for exact specifications.
Electrical
Standard is 208/60/3 phase.
Two dedicated electrical connections are required;
one, three phase and one interlock/control single
phase. See the electrical chart for the proper
electrical requirements. Manufactured to be
permanently connected. Consult your KES or local
Taylor distributor for cord and receptacle
specifications as local codes allow.
Electrical Total
Amp
Total
KW
Interlock/
Control
Voltage
Interlock
Fuse
Size
208/60/3 30 8.4 120/60/1 7A
240/60/3 24 8.4 120/60/1 7A
200/50/60/3 27 8.4 100/60/1 4A
220/380/60/3 14 8.4 220/60/1 4A
220/50/60/3 30 9.0 120/60/1 7A
400/50/3n~ 4w 14 8.4 220/50/1 4A
Gas
Two ceramic infrared burners: 30,000 BTUH each.
Manifold pressure: 3.5” w.c. natural, 10.5” w.c.
propane.
Dimensions
Width: 38” (965 mm)
Depth: 39-3/4” (1010 mm)
Height : 49-9/16 to 54-9/16” (1258 to 1385 mm)
Cooking Surface Height: 29 to 34” (737 to 864 mm)
Floor Clearance: 3-3/8 to 8-3/8” (86 to 213 mm)
(Casters may be adjusted.)
Approximate Weight
Net: 861 lbs. (390.5 kgs.)
Crated: 970 lbs. (440.0 kgs.)
Volume
53.7 cu. ft. (1.52 cu. m.)
Figure 3
