McDonald's Intelligap Grills
Introduction
150520
Model C842 Specifications
See the data label for exact specifications.
Electrical
Standard is 208/60/3 phase.
Three dedicated electrical connections are required;
two, three phase and one interlock/control single
phase. See electrical chart for proper electrical
requirements. Manufactured to be permanently
connected. Consult your KES or local Taylor
distributor for cord and receptacle specifications as
local codes allow.
Electrical Total
Amp
Total
KW
Interlock/
Control
Voltage
Interlock
Fuse
Size
208/60/3 69 25 120/60/1 10A
220/50/60/3 66 25 220/50/60/1 10A
220/380/60/3 38 25 220/60/1 10A
400/50/3n~4w 32 22 230/50/1 10A
Dimensions
Depth: 38” (965 mm)
Width: 37-7/8” (962 mm)
Height : 50-1/2 to 55-1/2” (1283 to 1410 mm)
Cooking Surface Height: 29 to 34” (737 to 864 mm)
Floor Clearance: 5-3/16 to 10-3/16”
(132 to 259 mm) (Casters may be adjusted.)
Approximate Weight
Net: 940 lbs. (426.4 kgs.)
Crated: 990 lbs. (449.1 kgs.)
Volume
54 cu. ft. (1.51 cu. m.)
Figure 6
