9
McDonald's Intelligap Grills
Introduction
150520
Model C836 Specifications
See the data label for exact specifications.
Electrical
Two dedicated electrical connections are required.
See the electrical chart for the proper electrical
requirements. Manufactured to be permanently
connected. Consult your KES or local Taylor
distributor for cord and receptacle specifications as
local codes allow.
Electrical Total
Amp
Total
KW
Interlock/
Control
Voltage
Interlock
Fuse Size
400/50/3n~ 16 8.8 230/50/1 4A
Dimensions
Width: 20” (508 mm)
Depth: 32-5/8” (829 mm)
Height : 48-1/2” to 53-1/2” (1232 to 1359 mm)
Cooking Surface Height: 29 to 34” (737 to 864 mm)
Floor Clearance: 5-5/8 to 10-5/8” (143 to 270 mm)
(Casters may be adjusted.)
Approximate Weight
Net: 386 lbs. (173.7 kgs.)
Crated: 466 lbs. (209.7 kgs.)
Volume
33.1 cu. ft. (0.9 cu. m.)
Figure 4
