Taylor C834 User Manual

138
Parts
McDonald's Intelligap Grills
Transformer A. - X73649 (60 Hz) -26 (50 Hz) (C845)
Figure 79
ITEM DESCRIPTION PART NO.
1 TRANS.-100VA 120/208/240 PRI 079800-24
2 BUSHING-SNAP 3/4ID X 1"OD 053144
3 SCREW-8X1/2 SLTD HEX WASH 075763
4 FILTER-CORCOM 6EH1 040140-001
ITEM DESCRIPTION PART NO.
5 BLOCK-TERMINAL 3P 20A 300V 051331
6 BUSHING-SNAP 5/8ID X 3/4OD 017462
