McDonald's Intelligap Grills
Introduction
150520
Model C845 Specifications
See the data label for exact specifications.
Electrical
Standard is 208/60/3 phase.
Two dedicated electrical connections are required;
one, three phase and one interlock/control single
phase. See the electrical chart for the proper
electrical requirements. Manufactured to be
permanently connected. Consult your KES or local
Taylor distributor for cord and receptacle
specifications as local codes allow.
Electrical Total
Amp
Total
KW
Interlock/
Control
Voltage
Interlock
Fuse
Size
208/60/3 22 7.8 120/60/1 10A
200/50/60/3 23 7.8 100/50/60/1 10A
220/380/60/3 12 7.8 230/60/1 10A
220/50/60/3 20 7.8 220/60/1 10A
400/50/3n~4w 11 7.8 230/50/1 10A
Gas
Three ceramic infrared burners: 25,000 BTUH each.
Manifold pressure: 3.5” w.c. natural, 10.5” w.c.
propane.
Dimensions
Width: 38” (965 mm)
Depth: 38-1/2” (978 mm)
Height : 50-1/2 to 55-1/2” (1283 to 1410 mm)
Cooking Surface Height: 29 to 34” (737 to 864 mm)
Floor Clearance: 3-3/4 to 8-3/4”
(96 to 223 mm) (Casters may be adjusted.)
Approximate Weight
Net: 923 lbs. (418.7 kgs.)
Crated: 1032 lbs. (468.1 kgs.)
Volume
52.6 cu. ft. (1.49 cu. m.)
Figure 8
