McDonald's Intelligap Grills
Platen A.-Serv WA - X73598-23 / -21 (C842) Parts Identification
ITEM DESCRIPTION PART NO.
1 SHIELD-PLATE TUBE 072467
2 O-RING-1-1/16OD X .103W 052733-118
3 SHIELD-COUPLING FRONT 072926
4 SHIELD-PLATE SHROUD-OUTR 072466
5 SHIELD-PLATE SHROUD 072465
6 WASHER-1/4 EXT TOOTH LOCK 000656
7 SCREW-12-24X1/2 TORX DRIVE 058720
8 SHIELD-PLATE TUBE INNER 072467-1
9 SHIELD-HEAT 072422
10 INSULATION-CER FBR 072421
11 SHIELD-COUPLING REAR 072927
12 O-RING-1-3/16OD X .103W 052733-120
13 SHROUD A.-PLATEN X73466
14 SCREW-10-32X7/16 LAT HD 065717
ITEM DESCRIPTION PART NO.
15 GASKET-GORE-TEX .250 DIA 074972-52
16 CABLE-ADJUST-PLATEN 072458
17 NUT-10-32 HEX MACHINE
SCREW
038599
18 WASHER-#10 FLAT 18-8 SS 037841
19 THERMOCOUPLE-K TYPE SS
BRAID
079622
20 SCREW-8-32X5/16 SLTD RND 017552
21
CONTROL-LIMIT W/SCREWS
(C842-23, -23 PLATEN)
078721
CONTROL-HI LIMIT 550F NO
RESET (C842-60, -21 PLATEN)
074165
* SEALANT-PIPE LOCTITE 567 .2 053884
* ADHESIVE-LOCTITE #271 .5ML 073582
* SEALANT-HEAT RESISTANT 076784
*LOOSE PARTS NOT SHOWN
