41
McDonald's Intelligap Grills
Controls and Systems
Gap Calibration
Step 1
From the SYSTEM SET UP menu, press the
key until the screen displays “GAP CALIBRATION.”
(Note: The factory default setting is .015 for all three
motors.)
GAP CALIBRATION
+.000 +.000 +.000
Step 2
Using the 10:1 gapping rod, check the four corners
of the platen.
Step 3
Use the keys to adjust the gaps. If the
gaps are too low, use the key to raise the
platen. If the gaps are too high, use the key to
lower the platen.
Note: Gap changes will not be recognized until the
Auto-Level Sequence has been completed.
Step 4
Pay close attention to the display. The motors are in
sequence as follows: RIGHT - FRONT - LEFT.
Press the keys to move to the other
motors.
Step 5
After changing the gap settings, press the key
once and then press the key.
Step 6
Press the RAISE button to raise the platen.
Step 7
Press the key twice and then press the
key to Auto-Level the platen. (See Auto Leveling on
page 23.)
IMPORTANT! Always Auto-Level the platen
when changing the gaps. If the platen is not
re-leveled, the offsets will show the changes, but the
motors will still have the previous settings.
Step 8
Place the platen into STANDBY and check the gaps.
Repeat these steps, if needed.
Auto Threshold
Auto Threshold is the minimum gap setting that the
platen will recognize a product. Anything below
0.020 will not be recognized.
IMPORTANT! DO NOT adjust the Auto Threshold
gap setting.
Step 1
From the SYSTEM SET UP menu, press the
key until the screen displays “AUTO THRESHOLD”.
AUTO THRESHOLD
0.020
Step 2
Press the key to return to the AM/PM Mode.
Step 3
Press the key to exit the programming mode,
or wait for the display to time out after 3-5 seconds.
