55
McDonald's Intelligap Grills
Controls and Systems
C842 Domestic Grill
The following table indicates the typical amp draw for the Model C842 (208/60/3):
C842 Grill Cord 1 Cord 2
Left Side of Grill L1L2 L2L3 L1L3 L1L2 L2L3 L1L3
Lower Front Plate
9.13
Lower Middle Plate
9.13
Lower Rear Plate
9.13
Top Back Platen
6.25
Top Front Platen
6.25
Totals
Middle of Grill L1L2 L2L3 L1L3 L1L2 L2L3 L1L3
Lower Front Plate
9.13
Lower Middle Plate
9.13
Lower Rear Plate
9.13
Top Back Platen
6.25
Top Front Platen
6.25
Totals
Right Side of Grill L1L2 L2L3 L1L3 L1L2 L2L3 L1L3
Lower Front Plate
9.13
Lower Middle Plate
9.13
Lower Rear Plate
9.13
Top Back Platen
6.25
Top Front Platen
6.25
Totals
Combined Totals 37.5 31.6 31.6 31.6 37.5 37.5
