McDonald's Intelligap Grills
C842/844 International Grill
The following table indicates the typical amp draw for the Model C842/844 (230400/50/3):
C842/844 Grill Cord 1 Cord 2
Left Side of Grill L1N L2N L3N L1N L2N L3N
Lower Front Plate
7.1
Lower Middle Plate
7.1
Lower Rear Plate
7.1
Top Back Platen
5.33
Top Front Platen
5.33
Totals
Middle of Grill L1N L2N L3N L1N L2N L3N
Lower Front Plate
7.1
Lower Middle Plate
7.1
Lower Rear Plate
7.1
Top Back Platen
5.33
Top Front Platen
5.33
Totals
Right Side of Grill L1N L2N L3N L1N L2N L3N
Lower Front Plate
7.1
Lower Middle Plate
7.1
Lower Rear Plate
7.1
Top Back Platen
5.33
Top Front Platen
5.33
Totals
Combined Totals 17.8 14.2 14.2 14.2 17.8 17.8
