DOOR PREPARATION
2
MARK AND DRILL PILOT HOLES
Select backset. Mark and drill pilot holes as shown.
CENTERLINE
BACKSET
DRILL 1/8” (3 mm) PILOT HOLE
1”
(25 mm)
2-1/8”
OR
1-1/2”
(54 mm) (38 mm)
DRILL 1/8” (3 mm) PILOT HOLE
