® REGISTERED TRADEMARK OF TAYMOR INDUSTRIES LTD.
6
DOOR PREPARATION
3.1
DRILL HOLES
a. Drill a 2-1/8” (54 mm) or 1-1/2” (38 mm) hole on the door face
from both sides to avoid wood splitting.
b. Use a 2” (51 mm) 6d common nail and press it from inside the
2-1/8” (54 mm) or 1-1/2” (38 mm) hole through the pilot hole to
mark centerlines on jamb exactly opposite center of deadbolt
latch hole.
1-1/2”
(38 mm)
OR
2-1/8”
(54 mm)
