- 24 -
Input of decimals
Some applications mentioned in the literature call for use of frequencies
with up to 2 decimals (i.e. 8.82 Hz). The F-SCAN COMPA CT offers this
feature starting w ith firmw are version Vx.05 or Vx.13.
1. Input a frequency with
decimals, i.e. 8.82 Hz.
F=0.00 shows,that the
Actual value of the
Frequency is 0 Hz.
2. Enter 8 Hz, press 8 times
3. Press softkey “DECI“
4. Press KEY-UP and hold
until decimal show s 82.
Confirm
with
CENTER.
