- 39 -
Technical data
Housing Plastic
Dimensions 105 mm x 66 mm x 19mm
Monochrome display 45mm x 24mm; 128 x 64 pi xel
Minimum frequency 1Hz
Frequency stability 30 ppm
Memory 10 or 100 user definable memory banks
Li st of 349 complete applications i f enabled
by user
Power supply Power supply: Input 100–240 VAC, 50–60 Hz,
Output 5 VDC, 500mA
Multi signal port OUT Sine signal, DC-Offset, Amplitude 10Vpp
Square full wave, Amplitude 0 … 24Vpp.
Square DC-Offset, Amplitude 0 … 12Vpp.
Output range 1Hz to 1.7 MHz sine, 1 Hz to 65 kHz square
Reduction of Amplitude on Frequencies above
1MHz is normal.
Changes to improve or simplify the product will be made without prior notice
Declaration of Conformity
Herewit h we declare:
TB-ELECTRONICS GmbH
Poststrass e 4
CH-9443 Widnau
that the followi ng product with the mar king
F-SCAN COMPACT Frequency Synthesizer
declare under our sole responsi bility to which this decl aration relates is in conformity with t he follo wing
standard:
EMC: 89/336, 92/31, 93/68
Harmoniz ed s tandards: EN 61326-1
Ratings, char acteristics 5VDC, 300mA
Widnau, 03 - 04 - 2008
legally bi nding Signature
