SWEEP function and SPECTRAL ZAP function
The SWEEP function is embedded in the start menu of the APPLICATION
LIST
If the symbol menu located in the center of the
bottom line of the display, is activated w ith F2 ,
a screen w ith the settings for the w ide band
application SWEEP opens.
lf F-MIN (the low est value of the band to
SWEEP) should be changed, press
Replaces the value 80000 by “0“ in the 1st
digit
The value 80000 shall be entered again,
Press 8 times.
Adds a „0“ as the 2nd digit.
Adds a “0“ as the 3
rd
digit. Another actuation
adds a “0“ as the 4
th
digit and a third one adds
a “0“ as the 5
th
digit. The value of F- MIN is
80000.
Confirm entries w ith
For entering F- MAX, proceed identically.
