EFFECTS – REVERB & EQ
low and high frequency ranges.
The two Color parameters can really change the
characteristics and style of the reverb – from “dark” and
“ambient” to “crisp” and “bright”.
Hi Lev & Lo Lev – (High Level/Low Level)
Range: -25 to 25
Use the Hi Lev and Lo Lev parameters to emphasize or
attenuate the selected Hi and Lo Color types.
Early
Range: -100 to 0dB
This parameter sets the level of the reverb’s initial
reflections (early reflections).
RevLev – Reverb Level
Range: -100 to 0dB
This parameter sets the Level of the reverb’s diffuse field.
Diff – Diffuse
Range: -25 to 25
With this parameter, you can fine-tuning the density of
the reverb’s diffuse field. It is set automatically when you
select a Decay time and allows you to reduce flutter in
the diffuse field to an absolute minimum.
Mix
Range: 0 to 100%
This parameter sets the relationship between the dry
signal and the level of the effect in this Effect Block.
OutLev – Output Level
Range: -100 to 0dB
This parameter sets the overall Output level of this Effect
Block.
Enable
Range: Off/On
The effect’s status. All settings are stored as part of the
preset even if this particular effect is disabled.
EQ – Parametric
The G-System features a 3 band parametric equalizer.
You can use this EQ either to shape the sound of
individual presets or – in the Lock Mode set via Utility –
as a “master EQ”.
For each band, the following parameters are
available:
Gain
Range: -12dB to +12dB
Use this parameter to attenuate or boost the frequency
range selected with the Freq(uency) parameter.
Freq
Range: 20Hz to 20kHz
This parameter sets the center frequency of the
frequency range that you want to attenuate or boost.
Width
Range: 0.1 to 4 octaves
This parameter sets the width of the frequency range
around the frequency specified by the Freq(uency)
parameter.
Enable
Range: Off/On
The effect’s status. All settings are stored as part of the
preset even if this particular effect is disabled.
