TDK-Lambda Genesys Series - LAN Reset

14
To change the IP address:
1. Press COMM button. Rotate Voltage Encoder until IP appears on the Voltage display, 1
appears on the Current display.
2. Press Current encoder to enter IP configuration. Rotate Voltage encoder to view the IP
address. Voltage display shows
IP1-IP4 by rotating Voltage encoder. The Current display
shows the corresponding IP address.
3. Rotate Current encoder to change the IP address. Press Current encoder to acknowledge new
IP address.
4. If another device is using the same address, Network Status LED turns Red.
5. To exit the menu, press the COMM button or the BACK button.
NOTES
1. Modifying the IP address via the Front Panel switches to STATIC IP addressing. (DHCP addressing is
disabled).
2. If power supply is turned on (AC or power switch) with a duplicate IP (same IP address is already
available in the network), IP address setting is 0.0.0.0.
5.3 MODBUS TCP Reset
To reset MODBUS TCP settings to its factory settings, perform the following steps:
1. Press the COMM button.
2. Rotate Voltage Encoder until OPT appears on the Voltage display, RESET appears on the
Current display. Press Current encoder.
3. SURE appears on the Voltage display, NO appears on the Current display. Rotate current
encoder one click clockwise.
YES appears on the Current display.
4. Press Current encoder to reset MODBUS TCP configuration to factory default settings.
Default MODBUS TCP settings are:
• DHCP is enabled.
• If DHCP fails to get a lease, 0.0.0.0 IP setting will be obtained:
IP Address
0.0.0.0.
Subnet Mask
255.255.254.0
Gateway Address
0.0.0.0
Hostname
Refer to Section 4.5
Domain Name
Empty
DNS Server #1
0.0.0.0
DNS Server #2
0.0.0.0
Ethernet Configuration Port 1
Auto
Ethernet Configuration Port 2
Auto
