Register address
Read holding registers (0x03)
Write single register (0x06)
Write multiple registers (0x10)
range
SCPI command
Read / Write
Data type
registers
909 V V
0-51065 [SOURce]:VOLTage:PROTection:LOW[:LEVel] RW uint16 1
910 V V V 0.0001-999.99 [SOURce]:CURRent:SLEW:DOWN RW float 2
912 V V V 0.0001-999.99 [SOURce]:CURRent:SLEW:UP RW float 2
914 V V V 0.0001-999.99 [SOURce]:VOLTage:SLEW:DOWN RW float 2
916 V V V 0.0001-999.99 [SOURce]:VOLTage:SLEW:UP RW float 2
918 V V
0,1 [SOURce]:POWer:STATe RW uint16 1
919 V V
1-53620 [SOURce]:POWer[:LEVel] RW uint16 1
920 V V
0,1,2 [SOURce]:VOLTage:MODE RW uint16 1
921 V V
0,1,2 [SOURce]:VOLTage:EXTernal:MODE RW uint16 1
922 V V
0,1,2 [SOURce]:CURRent:MODE RW uint16 1
923 V V
0,1,2 [SOURce]:CURRent:EXTernal:MODE RW uint16 1
924 V V
0,1 [SOURce]:CURRent:EXTernal:LIMit[:STATe] RW uint16 1
925 V
0-65535 STATus:OPERation[:EVENt]? R uint16 1
926 V
0-65535 STATus:OPERation:CONDition? R uint16 1
927 V V
0-65535 STATus:OPERation:ENABle RW uint16 1
928 V
0-65535 STATus:QUEStionable[:EVENt]? R uint16 1
929 V
0-65535 STATus:QUEStionable:CONDition? R uint16 1
930 V V
0-65535 STATus:QUEStionable:ENABle RW uint16 1
931 V V
0-31 SYSTem[:COMMunicate]:ADDRess RW uint16 1
932 V
9600-115200 SYSTem[:COMMunicate]:BAUDrate? R uint16 1
933 V V
0-4 SYSTem[:COMMunicate]:INTerface RW uint16 1
934
V
0,1 SYSTem:ERRor:ENABle W uint16 1
935 V
ASCII SYSTem:ERRor? R char 30
965
V
1-5 SYSTem:FRST W uint16 1
966 V
ASCII SYSTem:FIRMware[:VERSion]? R char 30
996 V
0,1 SYSTem:PANel:LOCK? R uint16 1
997 V
0-4294967295 SYSTem:PON:TIME? R uint32 2
999 V
0-4294967295 SYSTem:PON:TIME:AC? R uint32 2
1001 V V
0,1 SYSTem:PRELoad[:STATe] RW uint16 1
1002 V V
0-10000 SYSTem:PSOK:DELay RW uint16 1
1003 V V
0,1 SYSTem:RANGe RW uint16 1
1004 V V
1-1000 SYSTem:RIN[:LEVel] RW uint16 1
1005 V V
0,1 SYSTem:RIN:STATe RW uint16 1
1006 V V
0,1,2 SYSTem:REMote[:STATe] RW uint16 1
1007 V V
0,1 SYSTem:SENSe[:STATe] RW uint16 1
1008 V V
0,1,2 SYSTem:SLEW[:STATe] RW uint16 1
1009 V
0-65535 SYSTem:TEMPerature[:AMBient]? R uint16 1
