INIT:CONT OFF
Trigger system is enabled for a single trigger action
INIT
Trigger initialize
*TRG
Trigger command
MODBUS TCP Registers programming:
Write 0x0001 to register 920
Select LIST Mode Sequence
Write 0x29E4 to register 396
Set voltage value 2 Volts
Write 0x53C8 to register 397
Set voltage value 4 Volts
Write 0x29E4 to register 398
Set voltage value 2 Volts
Write 0xA790 to register 399
Set voltage value 8 Volts
Write 0x68BA to register 400
Set voltage value 5 Volts
Write 0x53C8 to register 401
Set voltage value 4 Volts
Write 0x0000 to register 195
Set dwell value 0.5 Second (low register)
Write 0x3F00 to register 196
Set dwell value 0.5 Second (high register)
Write 0x0000 to register 197
Set dwell value 0.5 Second (low register)
Write 0x3F00 to register 198
Set dwell value 0.5 Second (high register)
Write 0x0000 to register 199
Set dwell value 1 Second (low register)
Write 0x3F80 to register 200
Set dwell value 1 Second (high register)
Write 0x0000 to register 201
Set dwell value 1 Second (low register)
Write 0x3F80 to register 202
Set dwell value 1 Second (high register)
Write 0x0000 to register 203
Set dwell value 1 Second (low register)
Write 0x3F80 to register 204
Set dwell value 1 Second (high register)
Write 0x0000 to register 205
Set dwell value 1 Second (low register)
Write 0x3F80 to register 206
Set dwell value 1 Second (high register)
Write 0x0005 to register 903
Indicates to load 5 points (mutual for Voltage and Dwell)
Write 0x0001 to register 496
Upload Voltage registers into power supply sequencer
Write 0x0001 to register 395
Upload Dwell registers into power supply sequencer
Write 0x0001 to register 498
Set AUTO step execution mode ”AUTO”
Write 0x0001 to register 93
Set list execution iterations ”1”
Write 0x0000 to register 1012 Select BUS trigger source via communication interface or front
panel
Write 0x0000 to register 69
Trigger system is enabled for a single trigger action
Write 0x0001 to register 68
Trigger initialize
Write 0x0001 to register 61
Trigger command
NOTES
1. Start condition: Assume power supply output is on; Initial voltage point is 0 Volts.
2. The example above demonstrates values for a 10 Volts rated power supply.
