7.12.12 WAVE Subsystem
[SOURce]
:WAVE
:COUN <NRf>
:CURR <NRf>
:LOAD <NR1>
:STEP
:STORe <NR1>
:TIME <NRf>
:VOLT <NRf+>
This subsystem receives parameters to create a sloped waveform of the output voltage or current.
WAVE:COUN
Sets the number of times that the list is executed before it is completed. The command accepts
parameters in the range 1 through 9999. Any number greater than 9999 is interpreted as INFinity.
Use INF if you wish to execute a list indefinitely.
SCPI Command Syntax [SOURce]:WAVE:COUNt <NRf+>
Parameters 1 to 9999 | INFinity
*RST 1
Examples WAVE:COUN 3 WAVE:COUN INF
Query Syntax [SOURce]:WAVE:COUNt? (if count>9999 the response is INF)
Returned Parameters <NR3>
WAVE:CURR
This command specifies the output current points in a waveform list. The current points are given
in the command parameters, which are separated by commas.
SCPI Command Syntax [SOURce]:WAVE:CURRent <NRf+> {,<NRf+>}
Default Suffix A
Examples WAVE:CURR 2.5,3.0,3.5 up to 12 parameters
Query Syntax WAVE:CURR?
Returned Parameters <NR3>
WAVE:LOAD
Loads Voltage or Current, Time, STEP parameter and counter values to a specific location in the
memory defined by numbers <1..4>.
SCPI Command Syntax [SOURce]WAVE:LOAD <NR1>
Examples WAVE:LOAD 3
Query Syntax none
Returned Parameters 1..4
