10.3 Isolated Programming & Monitoring Connector
Refer to Table 8-1 for detailed description of the Rear Panel Isolated Programming & Monitoring
connector. To provide the lowest noise performance, it is recommended to use shielded-twisted
pair wiring.
Refer to Fig.8-1 for description of the connector.
Isolated programming plug P/N: MC1.5/8-ST-3.81, Phoenix.
Fig.8-1: Isolated Programming & Monitoring connector
Terminal Signal name Function
Range 0-5/0-10V
IS510 option
Range 4-20mA
IS420 option
1 SHLD
Shield, connected internally to chassis of
the supply.
Chassis ground
2
+VPROG_ISO
Output voltage programming input 0-5/0-10V 4-20mA
3 +IPROG_ISO Output current programming input 0-5/0-10V 4-20mA
4 GND Ground for programming signals. Ground Ground
5 GND Ground for programming signals. Ground Ground
6 +VMON_ISO Output voltage monitoring output 0-5/0-10V 4-20mA
7 +IMON_ISO Output current monitoring output 0-5/0-10V 4-20mA
8 SHLD
Shield, connected internally to chassis of
the supply.
Chassis ground
Table 10-1: Detailed description of the Rear Panel Isolated Programming & Monitoring connector.
CAUTION:
When the Isolated Analog Option is installed, do not apply any signals to the non-isolated VPGM
and IPGM (J1-6 and J1-5) pins. All other J1 features may be used normally. Refer to Section 4.3.1 for
a description of J1 features.
1
2
3
4
5
6
7
8
Shield
+VPROG_ISO
+IPROG_ISO
GND
Shield
+IMON_ISO
+VMON_ISO
GND
