5.9.4 Save
This command saves the present state of the power supply to a specified location in memory. Up
to 4 states can be stored. Storage locations 1 through 4 are in nonvolatile memory.
Save Front panel setting:
1. Press MENU button. MENU (green) LED illuminates. “et” message appears on the Voltage
display.
2. Rotate Voltage Encoder until "MEMO" message appears on Voltage display.
3. Press Voltage Encoder. “e” message appears on Voltage display.
4. Press Voltage Encoder. “SA  e” message appears on Voltage display. Numbers “1
.. 4“ appear
on Current display.
5. Rotate the Current Encoder to select required number value and then press the Current
Encoder. Display blinks and returns to previous level.
5.9.5 Recall
This command recalls the present state of the power supply from a specified location in memory.
Up to 4 states can be stored. Storage locations 1 through 4 are in nonvolatile memory.
Recall front panel setting:
1. Press MENU button. MENU (green) LED illuminates. “et” message appears on the Voltage
display.
2. Rotate the Voltage Encoder until "MEMO" message appears on Voltage display.
3. Press Voltage Encoder. “ReC” message appears on Current Display.
4. Numbers “1
.. 4“ appear on Current display.
5. Rotate the Current Encoder to select required number value and then press the Current
Encoder. Display blinks and returns to previous level.
